NEW GEN 4 COYOTE “4X” – NOW AVAILABLE!
**Free freight to a commercial address with a dock/fork lift.
Residential delivery adds $200-300 depending on location.
The Ford Performance all-aluminum 5.0L Coyote Gen 4X crate engine is a modern 5.0L 32-valve DOHC V-8 that utilizes advanced features such as direct and port fuel injection, twin independent variable camshaft timing (Ti-VCT), high-flow aluminum cylinder heads, and 12:1 compression to deliver 460 horsepower and 420 ft.-lb. of torque (with premium fuel). The aluminum cylinder block features plasma transferred arc spray in liners, cross-bolted main bearing caps, and thick main bearing bulkheads for strength. The Gen 4X 5.0L Coyote features a single 80mm throttle body for easier packaging in various applications.
- 460 hp and 420 ft.-lb. of torque
- 12:1 compression ratio
- Hypereutectic aluminum pistons
- Sintered steel connection rods as used on the Boss 302 Mustang
- Forged steel crankshaft
- Single 80 mm “drive-by-wire” throttle body
- 9.5 quart steel oil pan
- Composite lightweight intake manifold
- Mustang GT 409 stainless steel exhaust manifold RIGHT SIDE ONLY
- Engine mount bosses and bell housing mount pattern common to 5.0L modular engines
- For control packs see M-6017-M50HM and M-6017-M50HA
- For alternator kit see M-8600-M50BALT, M-8600-M50ALTC or M-8600-M50ALTA
- 10R80 flexplate included
- For manual transmission flywheel please see M-6375-M50
- Engine weight: 445 lbs. without front accessory drive components
***Note: driver side exhaust flange utilizes 5.2L GT500 pattern***
This means Gen 1/2/3 headers WILL NOT FIT without modifications to the flange!!
